2025 Honda CRF300L ABS Rally at Great Lakes Honda

Standard

• Compression ratio - 10.7:1
• Displacement - 286 cc
• Bore and stroke - 76 mm x 63 mm
• Valve train - DOHC, 4 valves per cylinder
• Transmission - Six-speed
• Final Drive - #520 chain; 14T/40T
• Engine Type - Liquid-cooled single-cylinder
• Fuel Delivery - PGM-FI electronic fuel injection

Standard

• Warranty - 12 months, unlimited mileage, freely transferable warranty; extended coverage available with Honda Plus
• Tires - Front: 80/100-21, Rear: 120/80-18
• Brakes - Front: 256 mm disc, Rear: 220 mm disc
• Wheelbase - 1,455 mm (57.3 in.)
• Colour: Extreme Red
• ABS System - 2-channel ABS
• Seat height - 885 mm (34.8 in)
• Ground Clearance: 275 mm (10.8 in)
• Curb weight - 152 kg (335 lb) including required fluids and full tank of gas—ready to ride
• Fuel capacity -12.8 litres

Standard

• Front Suspension - 43 mm Showa inverted forks; 234 mm (9.2 in) travel
• Rear Suspension - Pro-Link Showa single shock; 260 mm (10.2 in) travel
